Flatbed loading with van-style weather protection. The curtain rolls back so a crane can pick straight down onto the deck, then rolls closed over the freight — no tarp crew, no climbing, no wet machinery.
Quick answer: A Conestoga is a flatbed or step-deck trailer with a retractable tarp on a rolling frame. It loads from the top and both sides like an open deck, then the curtain closes to protect freight from rain, road salt, and debris without any manual tarping.
On a Conestoga, a vinyl curtain rides on bows that slide along rails built into the deck. Retracted, the whole system stacks into roughly eight feet at one end and leaves the deck completely open — so machinery gets craned in from directly overhead or forked on from either side, exactly like a flatbed. Then it rolls shut in a couple of minutes and the freight is covered for the whole run.
The trade-offs are real and worth knowing up front. The tarp system adds roughly 2,000–3,500 lb of tare weight, so payload lands nearer 44,000 lb than a flatbed's 48,000. Usable height under the bows is about 8 ft over a standard deck — a drop-deck Conestoga buys that back to roughly 10 ft. And nothing over-dimensional fits: a load wider or taller than the curtain goes on an open deck and gets tarped instead.
Painted, wrapped, or precision freight that must stay dry
Side-loaded pallets that a dry van can only load end-first
Surfaces that road salt and rain will stain or pit
Repeat loads where on-site tarping is impractical or prohibited
A Conestoga is a flatbed or step-deck fitted with a retractable tarp system — a vinyl curtain on bows that rolls along rails on the deck. It opens for top and side loading like an open deck, then closes to protect the freight from weather without manual tarping.
For repeat machinery loads, a Conestoga wins: it removes 30–60 minutes of tarping each way, eliminates the fall risk of working on top of a load, and protects better than vinyl that can flap or tear. For a one-off, or anything over-dimensional that won't fit under the curtain, tarping an open flatbed is cheaper. Full comparison in our tarping guide.
Around 44,000 lb typically — the rolling tarp system costs roughly 2,000–3,500 lb of payload versus a bare flatbed. Interior height is about 8 ft over a standard deck, or roughly 10 ft on a drop-deck Conestoga.
No. The bows and curtain rails are weather protection, not rated tie-down points. Every strap and chain goes to the trailer deck — stake pockets, rub rails, D-rings, and winches — at an aggregate working load limit of at least half the cargo weight. See how we load and secure a Conestoga.
